DecanF2

DecanF2

Advanced Flexible Placer

80,000CPH (Optimum)

2 Gantry x 10 Spindles/Head

0402~55mm (H15mm)

Modular conveyor

Wide part Handling

DecanL2

DecanL2

Advanced Multi-Functional Placer

56,000CPH (Optimum)

2 Gantry x 6 Spindles/Head

0402~55mm,L75(H25mm)

Modular conveyor

Wide part Handling

DecanS1

DecanS1

Fast & Flexible Mounter

47,000 CPH(Optimum)

10 Spindles/1Gantry

03015~55mm(H15),L75mm

Highest performance among chip Mounters of the same class

DecanS2

DecanS2

Advanced Chip Shooter

92,000CPH (Optimum)

2 Gantry x 10 Spindles/Head

03015~55mm (H15mm)

Modular conveyor

Wide part Handling

Fox2

Fox2

Smart-Sized Modular Pick-and-Place

Placing & dispensing in single pass-through

Up to 7‘000 – 18‘800 cph per module

Up to 200 feeder lanes on 1 sqm

HM520

HM520

Cutting-edge Modular Mounter

80,000 CPH (Optimum)

2 Gantry x 20,6 Spindle/Gantry

0201~6mm/~55mm (H15mm)

Actual productivity is highest among machines of the same class

Puma

Puma

Relentless Strong Pick-and-Place

Optimum 18’100 cph

Optimum 145’000 dots/h

Up to 280 Feeder

PCB size 560 x 610 mm

SCMID

SCMID

Odd-Shaped Component Placer for Shield Cans

Super slim (width 680mm)

Improved handling capability of odd-shaped components

Capable for dual lane mixed

SCMIDP

SCMIDP

Odd-Shaped Component Placer for bond dispensing

Super slim (width 680mm)

Provides a dispenser head

Inverter placement(Option)

Label Feeder(Option)

SCMIJ

SCMIJ

Small, Multi Functional Odd-Shaped Component Placer

Super slim (width 680mm)

Odd-shaped components

Laser lighting

Back Lighting (option)

SLM100

SLM100

High-Speed, SMART LED Mounter

43,000CPH(Optimum)

0603~32mm

L1,200xW356

SM451

SM451

High Precision, Multi Function Component Placer

Chip 8,500CPH/QFP 4,000CPH

0603~55㎜ x 42mm(H28㎜)

L460mmxW420mm(Standard)

SM471

SM471

Fast Chip Shooter

78,000CPH

2 Gantry x 10 Spindles/Head

0402(01005")~14mm(H12mm)

SM481Plus

SM481Plus

Fast Flexible Placer

40,000CPH

1 Gantry x 10 Spindles/Head

0402(01005")~42mm(H15mm)

SM482Plus

SM482Plus

Multi-Functional Placer

30,000CPH

1 Gantry x 6 Spindles/Head

0402~55mm(H15mm)

SM485

SM485

Wide Ranged Component Placer

4+1Spindles/1Gantry

22,000CPH(Optimum)

Force Control/Gripper nozzle

Backlight and Laser Lighting

SM485P

SM485P

Smart Hybrid Mounter

4 Spindles/1Gantry

0603~55mm(H32),L150mm

Force Control/Gripper nozzle

Backlight and Laser Light

Hight Sensor/PBI
